55' Discovery Yachts Discovery 55 Mk II

Discovery 55 for the new construction in 2017-2018 only.
We do not have "Discovery 55 Mk II" in the stock!
The new version of the classic and winning design of the Discovery 55 has come to fruition from the wealth of
experience of Discovery owners. Drawing from the knowledge of hundreds of thousands of miles of how the boat is
used, the Mark II 55 improvements include even more light in the raised saloon; a sleek profile similar to our stylish
flagship – the Discovery 67; flush deck hatches and improved sunbathing areas. Significant options include a more
spacious cockpit and twin vertical portlights in the master cabin.
Hull Construction
• Composite construction with high density foam core
providing exceptional stiffness and insulation. Laid up with
vacuum technology for complete structural integrity
• Vinylester resins are used throughout the hull for added
strength and osmosis prevention
• A Kevlar layer forward further enhances the impact
strength of the hull
• Non pigmented gel is used below the waterline to help
prevent osmosis
• 2 layers of epoxy as a barrier against moisture ingress
• 1 year manufacturer’s warranty - 5 year hull guarantee
against osmosis
• White gel coat with blue boot top and caveta line as
standard with other colour options available
• 2 x coats of anti-foul in colour of your choice
• Two forward watertight bulkheads providing sealed
buoyancy and safety
• 9,500kgs (20,500lbs) shaped lead keel and a depth of
2.23m (7”3”) provides a ballast ratio of 42% providing
maximum stability and comfort (1.8m shoal draft available
as an option)
Deck
• Composite construction with foam core providing
strength, thermal and acoustic insulation.
• All load-bearing areas have marine-ply core and backing
plates for added strength
• White gel coat with black mullions
• Teak decks & capping rail
• Joined to the hull with bonding paste and stainless bolts
for strength
• All bulkheads are laminated with epoxy paste into the
deck for strength and stiffness
Certification:
Supplied with CE
category A – Ocean

page 5
Engineering
• 24” Gori 3-blade folding propeller - for efficiency under
power or sail
• Walk-in engine room with the very best sound insulation
• Yanmar 160hp (118kW) engine
• Single lever engine control at helm
• Low noise electric engine room fan
• Automatic fire extinguishers in engine room
• Bow thruster with dedicated battery (230 lbs / ft thrust)
Stern thruster available as an option
• 5 kW Onan generator
• Eberspacher (Espar) Hydronic M10 central heating in all
cabins
• Fuel: Total of 1334 litres (352 US gals) in three polyethylene
tanks
• Analogue fuel and water tank gauge for quick and easy
reference
• 55 Amp 12v alternator for charging the start battery
• 110 Amp 24v alternator for charging the main domestic
batteries
Electrics
• Marine grade tinned cabling is used throughout. This
reduces corrosion and provides longevity of all electrical
systems
• Isolation transformer is fitted as standard to provide high
level electrical safety on board and galvanic protection for
all electrical items anywhere in the world
• 230v sockets throughout (110v optional)
• 12v socket fitted to navigation desk with discrete stowage
for mobile phone charging
• Efficient 24v (480 a.h.) house gel batteries
• Battery charging via shore power, or on board 5kW
generator & charger
• Engine and generator start batteries with built in ‘jump start’
system for greater reliability
• 3kW multivolt battery charger
• 230v / 50Hz shore power (USA pack available as option)
• 32 Amp 15m (16yd) shore power cable with female socket
• LED internal lighting throughout for lower power
consumption
• Halogen navigation, boom and deck light with optional LED
upgrade
• Nightlights throughout the boat
Navigational Electronics
• Sailing instruments (wind direction / speed, depth, boat
speed) – Raymarine i70
• Stand alone GPS (Garmin 152)
• Lewmar direct drive autopilot motor with Raymarine
evolution course computer and P70 head units at helm
and internal raised navigation station
• Raymarine E95 chart plotter and 4kW digital radar with
integrated AIS system
• Icom M423 VHF with DSC and masthead antenna
• Radar reflector - Passive
